Intel Core (BX80768265F) Ultra 7 Processor 265F Processor 20 Threads, 2.4GHz up to 5.3GHz Turbo,LGA 1851 Socket, 30MB Cache, 65W, Maximum Turbo Power182W

Intel Core Ultra 7 Processor 265F

Specifications

CPU Specifications

Total Cores
20

# of Performance-cores
8

# of Efficient-cores
12

# of Low Power Efficient-cores
0

Total Threads
20

Max Turbo Frequency
5.3 GHz

Intel Turbo Boost Max Technology 3.0 Frequency
5.3 GHz

Performance-core Max Turbo Frequency
5.2 GHz

Efficient-core Max Turbo Frequency
4.6 GHz

Performance-core Base Frequency
2.4 GHz

Efficient-core Base Frequency
1.8 GHz

Cache
30 MB Intel Smart Cache

Total L2 Cache
36 MB

Processor Base Power
65 W

Maximum Turbo Power
182 W

Intel Deep Learning Boost (Intel DL Boost) on CPU
Yes

AI Software Frameworks Supported by CPU
OpenVINO, WindowsML, DirectML, ONNX RT, WebNN

CPU Lithography
TSMC N3B

Memory Specifications

Max Memory Size (dependent on memory type)
256 GB

Memory Types
Up to DDR5 6400 MT/s

Max # of Memory Channels
2

ECC Memory Supported
Yes

GPU Specifications

Graphics Output
n/a

Xe-cores
0

Intel Quick Sync Video
No

# of Displays Supported
0

NPU Specifications

NPU Name?
Intel AI Boost

NPU Peak TOPS (Int8)
13

Sparsity Support
Yes

Windows Studio Effects Support
Yes

AI Software Frameworks Supported by NPU
OpenVINO, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

Direct Media Interface (DMI) Revision
4

Max # of DMI Lanes
8

Intel Thunderbolt 4
Yes

Scalability
1S Only

PCI Express Revision
5.0 and 4.0

PCI Express Configurations ?
Up to 1x16+2x4, 2x8+2x4, 1x8+4x4

Max # of PCI Express Lanes
24

Package Specifications

Sockets Supported
FCLGA1851

Thermal Solution Specification
PCG 2022C

Max Operating Temperature
105 C

Package Size
45 mm x 37.5 mm
